Detailed：
储能系统规格书 | LFP-280Ah | 232.9kWh | 100kW
| 电池类型 Battery Type | LFP-280Ah 磷酸铁锂电芯 |
|---|---|
| PACK配置 PACK Configuration | 1P525 / 46kWh |
| 成组方式 Grouping Method | 1P260S |
| 配置电量 Configured Capacity | 232.9kWh 电池实际配置电量 |
| 额定充放电功率 Rated Charge/Discharge Power | 100kW |
|---|---|
| 额定电压 Nominal Voltage (per cabinet) | 单柜电压 768V (基于1P260S平台) |
| 电池工作电压范围 Operating Voltage Range | 750-1000V 可根据 DOD 调整 |
| PCS 交流输出 AC Output (3P3W) | 380V (-15% ~ +10%) |
| 充放电倍率 Charge/Discharge Rate | 0.5P |
| 最大系统效率 Max System Efficiency | ≥88% |
| 最大循环效率(无辅助电源) Round-trip Efficiency (No Aux) | ≥93.5% |
| PCS 效率 PCS Efficiency | 最大98% |
| 系统循环寿命(次) Cycle Life | ≥6000 (EOL80%) | ≥8000 (EOL60%) |
| 系统防护等级 Protection Class | IP55 |
| 防雷等级 Lightning Protection Level | 1级 |
| 工作环境温度 Operating Temperature | -25℃ ~ +55℃ |
| 整机内部温度控制 Temperature Control | 液冷系统，温差 ≤3℃ |
| 允许海拔高度 Max Altitude | ≤4000m |
| 热管理方式 Thermal Management | 风冷(PCS) + 液冷(电池包) |
| 消防方案 Fire Protection | 气溶胶 |
| 噪声水平 Noise Level (dB(A)) | ≤75 dB(A) |
| 整机对外通讯接口 Communication Interface | CAN / LAN / RS485 / 4G |
| 重量 Weight | 2600 kg |
| 尺寸 (高*宽*深) Dimensions (H*W*D) | 2200mm × 1343mm × 1300mm |
