Detailed：
电池组数量Number of Modules1层电池组1 Modules2层电池组2 Modules3层电池组3 Modules4层电池组4 Modules5层电池组5Modules电池组标称电压Ba
| 电池组数量 Number of Modules | 1层电池 组1 Modules | 2层电池组 2 Modules | 3层电池组 3 Modules | 4层电池组 4 Modules | 5层电池组 5Modules |
| 电池组标称电压 Battery pack nominalvoltage | 51.2V | 51.2V | 51.2V | 51.2V | 51.2V |
| 电池组能量 Battery packenergy | 5.12kWh | 10.24kWh | 15.36kWh | 20.48kWh | 25.6kWh |
| 电池类型 Battery Type | 磷酸铁锂电芯 LiFePO4 | 磷酸铁锂电芯LiFePO4 | 磷酸铁锂电 芯LiFePO4 | 磷酸铁锂电芯 LiFePO4 | 磷酸铁锂电芯 LiFePO4 |
| 尺寸 Size (L'W*H) | 600*315*453mm | 600*315*640mm | 600*315*804mm | 600*315*980mm | 600*315*1300mm |
重量 Weight | 约105KG | 约150KG | 约195KG | 约240KG | 约285KG |
| 电池内阻 Internal resistance | ≤30m 0 | ≤30m0 | ≤30m0 | ≤30m 0 | ≤30m 0 |
| 标准充电电流 Standard charge current | 20A(0.2C) | 20A(0.2C) | 20A(0.2C) | 20A(0.2C) | 20A(0.2C) |
| 标准放电电流 Standard Dischargecurrent | 100A(1.0C) | 100A(1.0C) | 100A(1.0C) | 100A(1.0C) | 100A(1.0C) |
| 最大持续放电电流 Maximum continuousdischarge current | 100A(1.0C) | 100A(1.0C) | 100A(1.0C) | 100A(1.0C) | 100A(1.0C) |
| 充电电压 Operating voltage range | 56.0V~57.6V | 56.0V~57.6V | 56.0V~57.6V | 56.0V~57.6V | 56.0V~57.6V |
